Racerstar SPROG X 2206 2300kv Motor (Set of 5 - Blue)

Racerstar SPROG X 2206 2300kv Motor (Set of 5 - Blue)

Product #: 70212
Out Of Stock

The SPROG X is Racerstar's next generation of multirotor motors. With the same reliable performance that far exceeds its price, this pack of five motors is an amazing value, especially for beginners who want to get in the air quickly and start testing their skills. For the price, you can almost think of it as a buy 4 get 1 free - and typical to FPV drones, that extra motor will surely come in handy!

Note: All motors are CW with silver lock nuts.


  • Motor KV: 2300KV
  • Idle Current (Io/10V): 1.52A
  • Battery: 3-4S lipo battery
  • Max. Con. current: 38A
  • Max.Con. power: 608W
  • Motor Resistance (RM): 0.0372Ω
  • Max thrust: 1287g (4S/5")
  • Stator Diameter: 22mm
  • Stator Thickness: 6mm
  • Motor Diameter: 27.7mm
  • Shaft diameter: M5
  • Motor Body Length: 18.7mm
  • Overall Shaft Length: 33.7mm
  • Bolt holes spacing: 16/19mm
  • Bolt thread: M3
  • Framework: 12n14p
  • Axis Diameter: 4mm
  • No. of cells: 3-5s
  • Weight: 35.8g (W/O Silicone Wire)
  • Recommend Propeller: 5 Inch
  • CW Thread


  • 5x 2206 2300KV CW Motor (Blue)
  • 1x bag of screws (24pcs M3*8mm & 24pcs M3*10mm)
