Hobbywing XRotor Race Pro 2207 2650Kv Motor - Blue

Hobbywing XRotor Race Pro 2207 2650Kv Motor - Blue

Product #: 70358
Price:
Stock:
Out Of Stock
Store:
getfpv.com

Reviews:

The Hobbywing XRotor 2207 Race Pro Motor has been designed for the top levels of competitive FPV racing. Engineers have spent time working with top pilots to repeatedly confirm feedback. These motors have been fine-tuned to provide extreme power, with rapid response to throttle commands. Testers were surprised by the ultra smooth and precise response through all speed ranges and course conditions.

Features

  • Structural strength design

The snap-fit shaft and endbell design provide a seamless fit and finish. Combined with respected EZO bearings, the motors are smooth and true. This provides improved bearing life and reliability. The new stators are a complete redesign and focus on overall efficiency under load.

  • Ultra lightweight design

The new 2207 motors have been developed to push the limits of durability while remaining extremely lightweight. High quality 7075 aluminum and titanium shaft not only reduce weight but provide reliability and strength.

  • High quality 7075 aluminum

Along with the high-precision CNC Machining technology, both components produce an improved strength and axial concentricity

  • Hollow Titanium-Alloy Shaft

Reduces shaft's overall weight by 50% compared to standard motor shaft designs.

  • EZO bearings

Imported Japanese EZO bearings are the best available, providing longer life, lower noise, smoother operation, smaller clearance, and improved overall tolerances.

  • Ultrathin (.1mm) Silicon steel laminations

With less iron loss and heat generation, these laminations produce higher efficiency. Using the strongest and most heat resistant NbFeB magnets ensure maximum torque under load, and excellent consistency across the motors operating ranges.

Specifications

  • KV Rating: 2650KV
  • LiPo Cells: 4S
  • No-Load Current (A/10V): 1.4A
  • Motor Resistance: 37mΩ
  • Max Continuous Current/Power: 51.40A/822.4W(4S)
  • Stator Diameter/Thickness: 22mm/7mm
  • Slot/Plot Count: 12S/14P
  • Motor/Shaft Diameter: 27.5mm/4mm
  • Motor Length (w/o,w/Shaft): 17.3mm/30.7mm
  • Weight: 31.79g/29.5(w/o wires)

Includes

  • 1x XRotor Race Pro 2207 2650KV Motor - Blue
