FrSky R9 Slim+ 915MHz Long Range Receiver

Product #: 70102
Price:
$26.99
Stock:
In Stock
Store:
getfpv.com

Reviews:

The FrSky R9 Slim+ receiver is the updated version of R9 Slim, with optimized performance and 2 detachable antennas. The R9 Slim+ has all the features of the R9 Slim with the flexibility to work with more external devices by incorporating the inverted SBUS and S.Port outputs.

Features

  • 915MHz (Non-EU Version)/ 868MHz(EU Version)
  • Performance optimized
  • 2 detachable Ipex connector antennas
  • Small and conveniently setup
  • Low latency and high precision
  • Support redundancy function
  • Smart Port enabled and support telemetry data transmission
  • Battery voltage detection
  • With RSSI output
  • With inverted SBUS and S.Port outputs
  • PCB protection with the conformal coating craftwork

Specifications

  • Dimension: 32*13.5*5mm (L × W × H)
  • Weight: 4.3g (with antennas)
  • Number of Channels:
  • Non-EU Version: 6/16CH (Telemetry)
  • EU Version: 6/8CH (Telemetry) / 6/16CH (Telemetry) / 6/16CH (No Telemetry)
  • With RSSI Output: Analog 0~3.3V
  • Operating Voltage Range: DC 3.5V~12.6V(3s Li-Battery)
  • Operating Current: [email protected]
  • Operating Range: Up to 10km or above
  • Firmware Upgradable
  • Compatibility: R9M and R9M Lite

Includes

  • 1x R9 Slim+ 915MHz 16CH Long Range Receiver
  • 2x 8pin cables

Resources

Note: Firmware updates must be done in order from oldest to newest release. Firmware tab is under the manual tab.

FrSky R9 Slim+ Downloads
